| Item | Value |
|---|---|
| Model Number | LPJG46801AENL |
| Part Status | Active |
| Connector Type | RJ45 |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Contact Finish Thickness | 6.00µin (0.152µm) |
| LED Color | Green - Yellow |
| Number of Cores per Jack | 8 |
| Shielding | Shielded, EMI Finger |
| Number of Ports | 1X4 Port |
| Features | Board Guide |
| Tab Direction | Down |
| Contact Finish | Gold |
| Configuration RX/TX | T,C |
| Turns Ratio RX/TX | 1CT:1CT |
| Operating Temperature | 0°C ~ 70°C |
Package Details: 20 pcs in 1 tray, 20 tray in 1 carton.
Carton Size: 37*30*30cm
Weight: 10KGS (400pcs) per carton
100 / 1000 / 2.5G / 5G / 10G Base-T 1xN RJ45 Connector
Applications: Suitable for industrial temperatures from –40 °C up to +85 °C. Compatible with Industrial Ethernet systems like EtherCAT or Profinet. Compliant with most IC’s for Ethernet applications such as Microchip, Broadcom, Marvell, Hubs, Routers, Switches, IP cameras, and IoT applications.
