Product Description

RJ45 Connector Overview
L869-1A1T-32 L834-1G1T-S7 Tab Up 10/100/1000 Base-t Low Profile RJ45 Connector With Leds
Products Description
Item RJ45 Female Connector
Part Number LPJK7436AHNL
Compatible With L869-1A1T-32 L834-1G1T-S7
Part Status Active
Connector Type Jack
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Application-Lan Ethernet(NoN PoE)
Number of Ports 1x1 Port
Speed 10/100/1000 Base-T
Latch Up
Cores per Port 8
Orientation 90° Angle (Right)
PCB Mount Angle SIDE ENTRY
Shield EMI Tabs With
LED Option Green/Yellow
PCB FR4
PCB Retaining Post T POST
Temperature -40°C TO 85°C
Bst Circuit Yes
AutomDX YES
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Turns Ratio RX/TX 1CT:1CT
Configuration RX/TX T,C
Product Presentation Product Options Matrix
Production Process 1 Production Process 2 Production Process 3
Quality Testing 1 Quality Testing 2 Quality Testing 3
Company Profile
Established in 1997, we are a professional designer and manufacturer in magnetic telecom and networking components. With an extensive line of state-of-the-art catalog products as well as custom capabilities.
We are a global supplier of magnetic telecom and networking components of OEMs, contract manufacturers and CEMs, supplying more than 10000+ customers over 200 countries. Building multi-warehouse systems in key areas and continuously increasing inventory, we are committed to becoming the world's leading Ethernet RJ45 connector and LAN transformer company.
Factory View 1 Factory View 2 Factory View 3
FAQ
1. Are you a factory or trading company?
We are a specialized manufacturer of magnetic telecom and networking components, such as RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
2. Can I get a sample before mass production?
Yes, we can offer you free samples to test quality, but you should cover the shipping cost.
3. What is your delivery time?
We have products ready to ship for stock items, and it takes 15-30 days for mass production.
4. What after-service can you offer?
We provide a one-year guarantee period and offer online technical support 24 hours a day.
5. Can you accept OEM/ODM orders?
Yes, please send an inquiry to us so that we can have a detailed discussion about your specific requirements.
6. What is your advantage?
We have 19 years of production experience and have partnered with leading global brands in the industry for many years.
Certifications and Quality Guarantee
