| Product Specifications |
| Part Number |
LS-SM3106-40C |
| Form Factor |
SFP |
| Max Data Rate |
622Mbps |
| Wavelength |
1310nm |
| Max Cable Distance |
40km |
| Connector |
Duplex LC |
| Media |
SMF |
| Transmitter Type |
DFB |
| Receiver Type |
PIN |
| EMC (Electro Magnetic Compatibility) |
Supported |
| DDM/DOM |
Supported |
| Protocols |
MSA Compliant |
| Temperature Range |
0 to 70°C / -40 to 85°C |
| Warranty |
5 Years |
| Sample |
Available |
View Our Solutions
Drawing on over 10 years of experience in chips and modules, fast speeds, small size, power savings, and high performance are integrated into every module. A full series of optical modules is provided for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
Support Full Range Of 622M SFP
| Part Number |
Data Rate |
Wavelength |
Distance |
Media |
DDM |
| LS-MM8506-S5C |
622Mbps |
850nm |
500m |
Multi-mode |
Yes |
| LS-SM3106-S5C |
622Mbps |
1310nm |
500m |
Single Mode |
Yes |
| LS-SM3106-02C |
622Mbps |
1310nm |
2km |
Single Mode |
Yes |
| LS-MM3106-02C |
622Mbps |
1310nm |
2km |
Multi-mode |
Yes |
| LS-SM3106-20C |
622Mbps |
1310nm |
20km |
Single Mode |
Yes |
| LS-SM3106-40C |
622Mbps |
1310nm |
40km |
Single Mode |
Yes |
| LS-SM5506-80C |
622Mbps |
1550nm |
80km |
Single Mode |
Yes |
| LS-SM5506-A0C |
622Mbps |
1550nm |
100km |
Single Mode |
Yes |
| LS-SM5506-A2C |
622Mbps |
1550nm |
120km |
Single Mode |
Yes |
Application Fields & Solutions
Optical Transport Networks
End-to-end DWDM solution is provided with almost all optical devices - from active modules to optical passive devices, including optical amplifier (EDFA & RFA), Mux & Demux, OPM, ROADM, MCS, OLP and OTDR etc.
Cloud and Enterprise
To meet the demand of mass data transmission in data centers, a series of high-speed optical modules has been developed with product rates ranging from 10G to 800G, providing high-quality optical interconnection solutions.
Wireless
High reliability and performance products with mature and efficient lasers and mainstream chip solutions are provided to customers worldwide. The solution includes Dark Fiber, WDM, Radio over Fiber, High Speed, Mid-haul and Back-haul which could meet all the needs of various scenarios in 4G/5G systems.
FTTx
Aiming at global communication network constructors, FTTx optical fiber access total solutions are provided covering all-optical or optical copper combined access solutions and products.
Subsystems
To ensure the normal operation of the communication line, the optical cable O&M solution is provided which integrates an optical line protection system (OLP) and an optical line monitoring system (OLM).
